DR 6010C
Simple addition to boost efficiency
Welcome the newly developed 3-line image sensor technology in the DR 6010C, which allows scans at an eye-raising 60ppm. All this can be achieved by any user, with one-touch job buttons.
  •      Fast and efficient handling
​​Featuring a versatile dual paper path, the DR 6010C handles diverse document types comfortably and effortlessly. The default U-turn path processes all your basic documents rapidly and smoothly, while the Straight Path feeder can process thicker items such as ID cards. For non-standard paper types such as multi-sheet carbonless paper, switch from automatic to manual sheet feeding mode to keep your scanning in smooth operation.
  • Energy-efficient
The DR 6010C meets the high standards of the ENERGY STAR Programme guidelines for energy efficiency, meaning it requires less energy to operate, thereby also reducing running costs. Along with an auto power on / off, which smartly reduces energy consumption when not in use, the DR 6010C does its part to protect the environment, without compromising features or performance.
​
  •   Auto -shading mechanism
​Document quality control is maintained and kept consistent by the DR 6010C’s automatic calibration process. Prior to each scan job, the image sensor shifts to calibrate itself against a special white shading surface to ensure uniform image quality with impressive precision and clarity each every time.​


​ ​
  • Benefits
  1. High speed colour scanning – 60 ppm at 200 & 300dpi
  2. Front-Feed design & straight paper path option
  3. Large 100 sheet feeding
  4. Energy efficient
  5. Advanced image processing
  6. Robust - duty cycle of 7,500 scans/day
  7. Bundled Capture Perfect
Detailed Features
  •  Productivity when it matters
​ The DR-6010C is our fastest departmental scanner yet, scanning a rapid 60-ppm in colour at resolutions of 200 & 300dpi. A large capacity 100 sheet automatic feeder enables significant batches to be processed, for more scans in less time.
  • Flexible and reliable
 Coupled with the operator appreciated front–feed design the DR-6010C also comes with a selectable straight paper path which can be used for the trouble-free scanning of plastic cards and thick cards up to 546g/m², or more fragile documents.
​
  • User friendly
The DR-6010C can be used across a mixed range of business scanning applications. The Scan-To- Job buttons speed up productivity by allowing batches to be quickly scanned and sent to pre-defined destinations or workflow applications. Canon’s CapturePerfect software is bundled with the DR-6010C, with a Capture Perfect Software Developers Kit (SDK) also available for easy, customised integrations.
  • Energy efficient
The DR-6010C doesn’t just save time, it cuts energy consumption too, being one of the most energy efficient devices in its class.

  • ​Optimum quality
   A huge range of powerful features such as Auto-Colour Detection, Text Orientation Recognition, Auto Paper Size and Deskew detection ensure superb quality and optimum efficiency.

  • Small yet build for tough workloads
Despite the DR-6010C being small enough to fit on any desktop it’s capable of taking on busy office requirements quickly and reliably with a suggested daily duty cycle of up to 7,500 scans a day.

Scanner Features
  • Special features
 Auto Page Size Detection, Deskew, Skip Blank Page, Text Oriantation Recognition, Auto Colour Detection, Colour Dropout (RGB/Custom), Enhancement (RGB/Custom), Moire Reduction, Prevent Bleed through/Remove Background, Border Removal, Batch Separation, Patch Code Separation (software), Punch Hole Removal, Scan Area Setting, MultiStream™, Rapid Recovery System, Ultrasonic Double Feed Detection, Job/User Registration.

Specifications for DR6010C
Type :Desktop sheet-fed scanner
Document Feeding:Automatic or manual sheet feeding
Document size :
  • Width :53 - 219mm (2.08 - 8.6in.)
  • Length :70 - 356mm (2.76 - 14in.)
  • Long Document Mode:up to 1,000mm (39.3in.)
Document thickness and weight  :
U-Turn path
  • Automatic feeding:  0.06 - 0.15mm, 52 - 128g/m2 (14 - 32lb. bond)
  • Manual feeding:  0.05 - 0.2mm, 42 - 157g/m2 (11 - 40lb. bond)
Straight path
  • Automatic feeding: 0.06 - 0.15mm, 52 - 128g/m2 (14 - 32lb. bond)
  • Manual feeding: 0.05 - 0.66mm, 42 - 546g/m2 (11 - 144lb. bond)
Business card size and thickness  :
  • Size : 53.9 x 85.5mm (2.12 x 3.37in.)
  • Thickness :0.76 ± 0.08mm (0.03 ± 0.003in.)
Feeding Capacity :10mm stack or 100 sheets of 80g/m2 (20lb. bond)

Scanning Element :3-line CMOS CIS

Light Source :LED (red, green, and blue)

Scanning Side : Simplex / Duplex

Scanning Modes :Black and White, Error Diffusion, High-Speed Text Enhancement, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level Grayscale, 24-bit Colour, Auto Colour Detection

Scanning Resolutions :100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi

Scanning speed : (A4 / LTR, Portrait)
  • B&W200dpi: 60ppm (Simplex), 120ipm (Duplex)
  • 300dpi: 60ppm (Simplex), 120ipm (Duplex)
  • Grayscale200dpi: 60ppm (Simplex), 120ipm (Duplex)300dpi: 60ppm (Simplex), 120ipm (Duplex)
  • Colour200dpi: 60ppm (Simplex), 120ipm (Duplex) 300dpi: 60ppm (Simplex), 84ipm (Duplex)
Interfaces : Hi-Speed USB 2.0

Scanner driver :ISIS / TWAIN

Useful functions : Job Function, Folio, Ultrasonic Double-Feed Detection, Rapid Recovery System, Moire Reduction, Prevent Bleed Through / Remove Background, Punch Hole Removal, ColourDropout, Auto Page Size Detection, Text Orientation Recognition, Skip Blank Page, Deskew, MultiStreamTM, Prescan, User Preferences.

Power requirements :AC220 - 240V (50 / 60Hz)

Power Consumption : 200V:30W (Scanning), 2.2W (Sleep mode)

Operating Environment :10 - 32.5°C (50 - 90.5°F) ,Humidity:20 - 80% RH
​
Dimensions : (W x D x H)Feed trays closed:318 x 278 x 185.5mm (12.5 x 10.9 x 7.3in.)

Weight :Approx. 6.5kg (14.3lb.)

Options / Consumables :Barcode Module, Exchange Roller Kit

Specifications are subject to change without notice.
  (Scanning speed may vary depending on PC environment, scanner settings, and other factor)
Bundled Software
  • CapturePerfect 3.0
  • KOFAX VRS Basic
