The Ricoh fi-7600 is a high-performance A3 production scanner designed for reliable, high-volume document throughput.
Ricoh / Fujitsu Production Series
Fi-7600
Production A3
Document Scanner
100 pages per minute. Ergonomic, rotating ADF design. High-volume, reliable A3 scanning for production environments.
01
Feed
300-sheet ADF, handles mixed batches from A8 to A3
02
Detect
Ultrasonic multifeed detection & iSOP technology
03
Scan
Dual CCD sensors, 100 ppm / 200 ipm duplex speed
04
Output
Automatic Stacker for neat, controlled paper ejection
§ 01
Production-grade performance
A
Rotating ADF
Ergonomic design allows the ADF to rotate up to 90°, supporting various workstation layouts and operator preferences.
B
Heavy-duty capacity
Large 300-sheet ADF and 100 ppm speed deliver maximum throughput for high-volume, centralized scanning.
C
Reliable handling
Intelligent Paper Protection (iSOP) and manual feed modes ensure safe handling of delicate, thick, or mixed documents.
D
High-speed connectivity
USB 3.0 interface ensures rapid data transmission for seamless document processing.
Ricoh fi-7600 production A3 scanner
- Production-level A3 scanning Designed for high-volume environments, the fi-7600 combines speed, durability, and versatility for all document sizes up to A3.
- Ergonomic rotating ADF The ADF can rotate up to 90 degrees, allowing for comfortable feeding from the front or side, optimizing workspace layouts.
- Heavy-duty throughput With a 300-sheet ADF and 100 ppm / 200 ipm speeds, this scanner is built to handle the most demanding production workloads.
- Smart protection Features Intelligent Sonic Paper Protection (iSOP) to detect paper issues and immediately halt scanning to prevent document damage.
- Intuitive operation Backlit LCD for status updates and PaperStream software ensure consistent image quality and efficient document batch processing.
Full technical specifications
| Scanner type | ADF (Automatic Document Feeder) / Manual Feed, Duplex |
| Scan speed (A4 landscape) | 100 ppm simplex / 200 ipm duplex (200/300 dpi) |
| Image sensor | CCD x 2 (front x 1, back x 1) |
| Light source | White LED array x 4 |
| Optical resolution | 600 dpi |
| Output resolution | 50–600 dpi, up to 1,200 dpi via driver |
| Max document size | 304.8 x 431.8 mm (A3) |
| Long page scanning | Up to 5,588 mm (220 in.) at 200 dpi |
| ADF capacity | 300 sheets (A4 80 g/m²) |
| Expected daily volume | Up to 30,000 sheets |
| Multifeed detection | Ultrasonic overlap detection, length detection |
| Interface | USB 3.0 (USB 2.0/1.1 compatible) |
| Dimensions (W x D x H) | 540 x 540 x 300 mm |
| Weight | 17 kg |
| OS compatibility | Windows 11 / 10 / Server versions |
Specifications sourced from Ricoh's official fi-7600 datasheet.
Product video
Coming Soon
Product Video In Progress
The official product video will be embedded here once it’s ready. Check back soon, or contact us for a live demo in the meantime.
Brochure
Coming Soon
Brochure Being Finalised
The official downloadable brochure for this model will be available here shortly. Contact us if you need the datasheet sooner.
IMPROVE YOUR FRONT-OFFICE WORKFLOW
Explore the official product details for the fi-7600.
§ 03
Frequently asked questions
The fi-7600 is built for high-volume production, with an impressive daily duty cycle of up to 30,000 sheets.
Yes, the scanner includes a manual feed mode that is perfect for scanning delicate, fragile, or bound documents that cannot be fed through the ADF.
The ability to rotate the ADF up to 90 degrees allows operators to feed documents from the side or the front, significantly improving ergonomics and adaptability to various workstation layouts.
If you have an exceptionally thick envelope or a document that is too rigid for the standard ADF path, you can flip the switch for Manual Feed Mode . This allows the scanner to process items without the same constraints as automated batch scanning.
