Print head: PF-03

Technology FINE (Photolithography Inkjet Nozzle Engineering)
Print Resolution (Max.) : 2400 x 1200dpi
Line Accuracy: ±0.1 % or Less
Minimum line Weight : 0.02mm
Number of Nozzles Matte Black: 5,120 Nozzles
Other Colours:            2,560 Nozzles per Colour
Droplet Size:4 Picoliter
Nozzle Pitch (Head Resolution): 1200dpi x Two Rows
Print Head Swath :1.07in.

Ink Tank

Ink Type Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K)
Pigment: Matte Black (MBK)
Model PFI-102
Ink Capacity : 130ml each (bundled starter ink: 90ml)
Number of Colours: 5
Ink Supply Method: Tubing system (independent ink tanks)
Nozzle Recovery System: Non-firing Nozzle Detection and Compensation
Printer Controller: L-COA Controller
Printer Memory : 256MB
Media feed : Top-loading Manual Feed, Front-loading Manual Feed, Top-loading Roll Feed
Media Width
Roll Feed, Manual Feed: 203mm - 610mm
Media size
Roll paper (width) :ISO - A3, A2, A1
JIS - B4, B2
ARCH - D (24" = 609.6mm)
Others - 8", 10", 14", 16", 17", 300mm, A3+ (329mm)
Cutsheet Manual feed from the top:   ISO - A4, A3, A3+, A2, A1, B4, B3, B2, DIN - C4, C3, C2, JIS - B4, B3, B2, ANSI - Letter (8.5 x 11"), Legal (8.5 x 14"), 11 x 17", 13 x 19", 17 x 22", 22 x 34", ARCH - 9 x 12", 12 x 18", 18 x 24", 24 x 36", Photo - 20 x 24", 18 x 22", 14 x 17", 12 x 16", 10 x 12", 10 x 15", 16 x 20" (US Photo size), Poster - 20 x 30", 300 x 900mm, Others - 13 x 22", 17 x 24"
Manual feed from the front:   ISO - A2, A1, B2, DIN - C2, JIS - B2, ANSI - 17 x 22", 22 x 34", ARCH - 18 x 24", 24 x 36", Photo - 20 x 24", 18 x 22", Poster - 20 x 30", Others - 13 x 22"
Printable Margins
Roll Feed All Sides:    3mm or 0mm for Borderless
Manual Feed   Left, Right, Top: 3mm, Bottom: 23mm (Front feed) or 3mm (Top feed)
Minimum Printable Media length
Roll Feed : 8.0" (203mm)
Top-loading Manual Feed : 11.0" (279mm)
Front-loading Manual Feed : 20.5" (520mm)
Maximum Print length
Roll Feed : 59" (18m)
Top-loading Manual Feed : 5.2" (1.6m)
Front-loading Manual Feed : 36.0" (914mm)
Media Cutter: Automatic horizontal cutting (Rotary cutter), independent unit
Media Thickness
Roll Feed : 0.07 - 0.8mm
Top-loading Manual Feed: 0.07 - 0.8mm
Front-loading Manual Feed : 0.5 - 1.5mm
Media Core Sizes: Internal diameter of roll core:       2" / 3"
Maximum Roll Outer Diameter :150mm

Software

Printing Software : imagePROGRAF Printer Driver, HDI Driver for AutoCAD / AutoCAD,
LT 2000 - 2008, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function)
Utilities: Media Configuration Tool
Applications: Digital Photo Front-Access, GARO Device Setup Utility, Poster Artist (optional)
Device Status: GARO Status Monitor, Remote UI
Printer language : GARO (Canon Proprietary), HP-GL/2, HP RTL
Operating Systems : Windows 2000 / XP / Windows Vista ,Macintosh OS 9 / 10 (PowerPC or Intel)

Interface

Standard (Built-in): USB 2.0 Hi-Speed, 10 / 100Base-T / TX
Optional : IEEE1394 (FireWire)
Acoustic Noise
Operation : 52dB (A) or Less
Standby : 35dB (A) or Less
Acoustic Power : 6.6 Bels or Less
Power Supply : AC 220 - 240V (50 - 60Hz)
Power Consumption
Operation Maximum : 100W or Less
Standby : (100 - 120V) 5W or Less (8W or less when IEEE1394 is mounted)
Standby: (220 - 240V) 6W or Less (9W or less when IEEE1394 is mounted)
Power Off :  1W or Less (Executive Order Compliant)
Certifications: UL, FCC Class B, CPS, CCC, ENERGY STAR (WW), RoHS directive
Operational Environment
Temperature: 15 - 30°C
Relative Humidity : 10 - 80% (No Condensation)
Dimensions (W x D x H) :997 x 870 x 989mm (with Printer Stand)
Weight (with Stand): Approx. 60kg
User Replaceable Items: Print Head (PF-03)
Ink Tanks (PFI-102)
Maintenance Cartridge (MC -16)

*1        For the information of purchasable media, contact your local sales representative.
*2        Maximum printable length varies according to the OS and application.
