OpticBook A300
OpticBook A300 can scan an A3 sized page in about 2.4seconds or a 200 page 8.5x11” book in about 20 minutes. Special book-edge design can scan any book without the book spine shadow and distorted text associated with book scanning on flatbed scanners or copiers. Pages are automatically cropped and rotated to the correct orientation and then saved to your choice of file formats including PDF and TIF.
Specification
Image Sensor: CCD
Optical Resolution: 600 dpi
Hardware Resolution: 600 x 1200 dpi
Scan ModesColor: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
Book Edge2mm
Scanning Speed2.48 sec (Color mode, 300dpi, A3)
2.10 sec (Grayscale/ B&W mode, 300dpi, A3)
Scanning Area (W x L)Max. 304.8 mm x 431.8 mm (12" x 17"), A3
Daily Duty Scan ( Sheets )5,000
Power Consumption< 36 W (operation), < 8 W (idle)
InterfaceUSB 2.0
Net Weight7.7 Kgs (16.96 Lbs)
Dimensions (W x D x H)623 x 400 x 133 mm (24.53” x 15.75” x 5.24”)
ProtocolTWAIN Compliant
OSWindows XP / Vista / 7 / 8
Hardware RequirementsPentium® IV 2.0 GHz processor
CD-ROM Driver
One available USB 2.0 Port
512 MB RAM (1GB or higher recommended)
800 MB free HDD space (1 GB or larger recommended)
Optical Resolution: 600 dpi
Hardware Resolution: 600 x 1200 dpi
Scan ModesColor: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
Book Edge2mm
Scanning Speed2.48 sec (Color mode, 300dpi, A3)
2.10 sec (Grayscale/ B&W mode, 300dpi, A3)
Scanning Area (W x L)Max. 304.8 mm x 431.8 mm (12" x 17"), A3
Daily Duty Scan ( Sheets )5,000
Power Consumption< 36 W (operation), < 8 W (idle)
InterfaceUSB 2.0
Net Weight7.7 Kgs (16.96 Lbs)
Dimensions (W x D x H)623 x 400 x 133 mm (24.53” x 15.75” x 5.24”)
ProtocolTWAIN Compliant
OSWindows XP / Vista / 7 / 8
Hardware RequirementsPentium® IV 2.0 GHz processor
CD-ROM Driver
One available USB 2.0 Port
512 MB RAM (1GB or higher recommended)
800 MB free HDD space (1 GB or larger recommended)
